- Description
| Microscope | ||
| Microscope |
Galilean Type |
|
| Magnification Change |
Revolving Drum |
|
| Total Magnification |
6X, 10X, 16X, 25X, 40X (S360) 10X, 16X, 25X (S360S) |
|
| Field of View |
Φ34.7mm(6X), Φ22mm（10X）, Φ13.5mm(16X), Φ8.5mm（25X），Φ5.5mm(40X) |
|
| Chin-rest
|
||
| Vertical Movement |
80 mm |
|
| Fixation |
LED | |
| Slit Illumination
|
||
| Slit Width |
0~14 mm continuous (slit becomes a circle at 14 mm) |
|
| Slit Length |
0~14 mm continuous |
|
| Aperture Diameter |
Φ14 mm, Φ10 mm, Φ5 mm, Φ3 mm, Φ2 mm, Φ1 mm, Φ0.2 mm |
|
| Slit Angle |
0°~180° |
|
| Slit Inclination |
5°, 10°, 15°, 20° |
|
| Filters |
Heat-absorbing filter, ND filter, Red-free filter, Cobalt Blue filter |
|
| Lamp |
3 V/3 W LED Module | |
| Power Supply
|
||
| Input voltage |
220 V/110 V±10% |
|
| Input frequency |
50 Hz/60 Hz |
|
| Power Consumption |
30 VA (max) |
|
| Output voltage |
Lamp 6 V, Fixation 3 V | |
Packaging
Dimension:
770 mm x 470 mm x 570 mm(L/W/H)
Weight:
Gross weight 26 kg
Net weight 18 kg
Shipping Information:
G.W: 24kg
Packing Size: 0.77m,0.47m,0.57m
Unit: Piece
