Description

Product Parameter
Power supply tension: 220V, 50Hz Fuse: F10AL/250V
Fuse: F1A/250V, F10AL/250V
Suction at 1500ml/min max, 850mmHg max
Ear rinsing with 37°C~42°C
Alternatively ear rinsing with 37°C~42°C with compressed air system
Compressed air for medication spraying, max. 3 bars
Electric power supply for LED, 12V, 10W, 0.83A, fuse: F1A/250V
LED cold light source 12V, 10W, 0.83A fuse: F1A/250V

Application:For ear, nose, throat diagnose and treatment

Standard equipment

STANDARD EQUIPMENT	Qty
LED Illuminating light	1
Spray gun	1
Suction gun	1
Blowing gun	1
Laryngoscope pre-heater	1
Built-in LED light source	1
Luxury thin film viewer	1
Blow-off equipment system (with warning system)	1
Instrument tray	2
Cotton cup	2
Medical bottle	7
Built-in waste tank	1
Built-in equipment recycle tank	1
Built-in immersion sterilization cup	1
Doctor chair	1
Vacuum pump	1
Compressor	1

Options

Options	Qty
1/3 CCD medical camera	1
LED cold light source	1
Fiber cable	1
Computer set	1
Pinter
Professional ent workstation software
LCD monitor	1
Ear rinsing system	1
Otoscope	1
nasoscope	1
Laryngoscope	1
ENT microscope	1
ENT chair	1

Package,
It is package by wooden standard export package, durable and safety.

ENT Chair:
Basic Patient Chair, CCEN-012

Technical parameter:

1.Voltage:AC220V,50Hz, AC110V,60Hz

2.Power:230W(max) and low power consumption, energy saving

3.Under weight pressure:250kg(max)

4.Seat height adjustment:(minimum) 500mm-650mm(maximum)

5.Backrest adjustment angle:90°

6.Pillow flex:100mm(folding, detachable)

7.Electro motor – 1/piece.

8.Wooden case packing size: 695*720*1230(mm)

9.Rough weight: 82kg；Net weight: 60kg

Standard Patient Chair, CCEN-011

Technical parameter:

1.Voltage:AC220V,50H

2.Power:230W(max) and low power consumption, energy saving

3.Under weight pressure:250Kg(max)

4.Seat height adjustment:(minimum) 560mm-710mm(maximum)

5.Length in the range of 1570 mm；Width in the range of 650mm;
Base in the range of 475mm; Section of seat in the range of 460-500 mm;
Section of back in the range of 560mm; Head restraint in the range of 225 mm;
Section of legs in the range of 340mm.

6.Backrest adjustment angle:90-135°

7.Pillow flex:100mm(folding, detachable)

8.Electro motor – 2/pieces.

9.Seat can be rotated 180°

10.Wooden case packing size: 790*750*1335(mm)

11.Rough weight: 112kg；Net weight: 80kg

Luxury Patient Chair, CCEN-010

Feature: The seat can be up & down, backrest can be forward & backward, arms
moves together with leg pads, seat can be rotated 180°.

1.Voltage:AC220V,50Hz. AC110V,60Hz

2.Power:230W(max) and low power consumption, energy saving.

3.Under weight pressure:250Kg(max).

4.Seat height adjustment:(min) 530mm-680mm(max)

5.Length in the range of 1950 mm；Width in the range of 625mm; Base in the range of 490mm;
Section of seat in the range of 460-460 mm; Section of back in the range of 550mm;
Head restraint in the range of 225 mm; Section of legs in the range of 330mm.

6.Armrest and backrest connections moving, the backrest can be adjusted from 90-180°.

7.Pillow flex:100mm (folding, detachable).

8.Electro motor – 2/pieces.

9.Seat can be rotated 180°.

10.Wooden case packing size: 1160x760x1285(mm) .

11.Rough weight: 170kg；Net weight: 115kg.

1/3 CCD medical camera

LED cold light source

Fiber cable

Computer set +Printer +Professional ent workstation software,
Application: Can analyze the result, and check the patient result and print our report.
