Parameters:
Highest output: 300W
Six working modes:
Monopolar:  pure cut，blend1, blend2,
contact coagulation, forced coagulation

Bipolar: bipolar coagulation
1. The electrosurgical generator is used to control bleeding and surgical cutting in all general and open surgical procedures
2. Touch control panel, three-way power output, with different audible and visual indication during the process of outputting.
3. Patient return electrode monitoring system and Power Peak System that provides surgeons with improved performance at Lower power settings, minimizing the risk of tissue damage.
4. Applicable for Prostate Vaporizing Surgical Operation(TUR), perfectly used under water.
  The electrosurgical generator can be cooperated with argon plasma coagulator, endoscope and laparoscope.
5. Pencil Remoting Output. The output power can be controlled by the remoting control pencil.

Technical Specifications
Power: 220V±22V, 50Hz±1Hz(110V±11V, 60Hz)
Operating frequency: 512KHz
Power rating: 880VA±10％

Six working modes:
Monopolar Cut
　　　a) Pure cut: 0W～300W( Load 800Ω)
　　　b) Blend1: 0W～250W(Load 800Ω)
　　　c) Blend2: 0W～150W(Load 800Ω)
Monopolar Coag
　　　d) Contact Coag: 0W～80W( Load 800Ω)
　　　e) Forced Coag: 0W～120W( Load 800Ω)
Bipolar
　　　f) Bipolar Coagulation: 0W～50W( Load 100Ω)
Power Consumption: ≤880VA

Configuration Sheet
Disposabe ESU pencil:   5pcs

Power Control Pencil:    1pc

Electrosurgical Pad:     10pcs

Electrosurgical pad cable:  1pc

Footswitch:           1set

Bipolar Forceps:  1set

Bipolar forceps cable       1pcs
