Description

Specifications

1, New generation Peltier technology, more stable, reliable and durable
2.7 inch color touchscreen, graphical protocol display
3, Effortlessly interchangeable reaction modules that change in seconds without tools.
4, bilingual interface (English and Chinese)
5, Unlimited protocol storage with USB flash drive

9 6 Module: 96 wells × 0.2 ml
9677 Module: 96 wells × 0.2ml + 77 wells × 0.5ml

Optional module: 384 module: 384-well module (without gradient): 9677 module + in situ adapter

Temperature
Block temperature range: 0 ～～ 105 ℃
Max. Ramp rate: 5 ℃ / sec
Temperature uniformity: ≤ ± 0.2 ℃ （to 95 ℃）

Heated lid
Innovative two-in-one cover (open / lifted)
Low temperature (＜ 30 ℃) block cover automatic shut-off heating function
Infinitely adjustable lid, fits all kinds of PCR tubes, strips and plates

Software
Max. 30 steps

100 typical cycles, max. 60,000 nesting cycles

Time / Temp. Increment / Decrement is available to perform Long PCR and Touchdown PCR

Automatic pause; Automatic restart after power failure

Infinite incubation time at low temperature for night work

Multi-user login with password authentication prevents viewing, copying and modification of protocols, ensuring user privacy and security

Tm calculator automatically calculates melting and annealing temperature by inputting two primer sequences, greatly improving work efficiency

The program wizard provides a quick method to create PCR protocols in a few steps

View 10 recent programs run for easy access

Get a detailed operation report, providing objective and accurate information for the entire experience

Effortlessly combine up to 50 A100 / 200 units for remote PC control and management

Other characteristics
Wide range power supply 85V-265V, 47-63Hz
Communication ports: USB2.0, LAN and RS232
Power consumption: 600 W max.
Certificate: ISO 9001: 2000, CE, RoHS
Dimension （L × W × H）: 362 × 256 × 255 mm
Net weight: 7.3 kg
