Newest Generation Peltier-based Technology, more Steady, Reliable and Durable
7”ColorFull Touch Screen, Graphical Display of Protocols
Effortlessly Interchangeable Reaction Modules that Swap in Seconds without Tools.
Bilingual Interface (English and Chinese)
Unlimited storage of Protocols with USB Flash Drive

9 6 Module：96wells×0.2ml
9677Module：96wells×0.2ml+77wells×0.5ml

Optional Module: 384 Module：384wells
(with gradient) Multi-purpose Module：9677 Module + In-situ Adapter

Temperature
Block Temperature Range: 0℃～105℃
Max. Ramping Rate: 5℃/sec
Temperature Uniformity: ≤±0.2℃（at 95℃）

Gradient
Column Uniformity: ≤±0.2℃（at 95℃）
Temp. Differential Range: 1～30℃
Gradient Capability: 12 Column

Heat Lid
Innovative Designed Two-in-One (Open/Lift) Lid

Auto Shut-off Heating Function of Lid at Low Temperature (＜30℃) of block

Steplessly Adjustable Lid, accommodates all kinds of PCR tubes,strips and plates

Software
Max.30 Steps

100 Typical Cycles, max. 60,000 nesting cycles

Time/Temp. Increment/Decrement is available for performing Long PCR and Touchdown PCR

Auto Pause; Auto restart after power failure

An Infinite incubation time at low temperature for overnight working

Multi-user log in with password-based authentication prevents from view, copy and alteration of protocols, ensure user’s privacy and safety

Tm calculator automatically calculates the melting and annealing temperature through input two primer sequences, greatly improve work efficiency

Program wizard provides a quick method for creating PCR protocols in a few steps

Display recent run 10 programs for easy access

Get detailed running report, providing objective and precise information for the whole experiment

Effortlessly Combine up to 50 units of A100/200 for remote control and management by computers

Other Features
Wide Range Power Supply 85V-265V, 50-60Hz
Communication Ports: USB2.0, LAN and RS232
Power Consumption： Max.600W

Certificate: ISO 9001:2000, CE, RoHS

Dimension（L×W×H）: 362×256×255mm

Net Weight: 7.3kgs
