Features:

■   It has the cooling device;

■   Double clamp-plates that can cast two gels at one time;

■   The tank body is made of the high transparent, insulative synthetic glass, and no leakage.

■  Electrodes are made by pure platinum ( the purity quotient of the noble metal≥99.95%)which have the features of corrosion resistance of electroanalysis and withstand high temperature.

Specifications:

■ Gel dimension (L X W): 125 × 100 (mm);

■  Runs up to 12 or 16 samples;

■  Comb thickness: 1.0 (mm) and 1.5 (mm);

■  Buffer volume: about 1350ml;

■  Size (L X W X H):160×150×170 (mm);

■   Weight: about 3.5 kg.

Applications:

It is used for protein electrophoresis experiments, it is simple and easy to use, and suitable for teaching and scientific research.

Suitable Electrophoresis Power Supply

CCL-DYY6C,
CCL-DYY7C,
CCL-DYY8C
