Features:

■  Made from high quality acrylic with platinum electrodes;

■  Latches on the gel holder cassette for easy handling;

■  Fast transferring speed and good transferringeffect;

■  A seamless, injection-molded transparent buffer tank prevents leakage and breakage;

■  Allows easy orientation for rapid, error free set-up;

■  An efficient design simplifies insertion and removal of the gel holder cassette from supporting body for transfer ( electrode assembly)

■  Compatible with the lid and the buffer tank of CCL-DYCZ24DN;

Specifications:

■ Pore plate combination for transferring dimensions: 95 × 87 (mm);

■ Max. power: 40W;

■ Continuous working time: ≥24 hours;

■ Buffer volume: about 400 – 450 ml;

■  Size(L X W X H):150×100×140 (mm);

■  Weight: about 1 kg.

Applications:

For transferring the protein molecule from the gel to membrane like Nitrocellulose membrane in the Western Blot experiment.

Suitable Electrophoresis Power Supply

CCL-DYY7C,
CCL-DYY10C,
CCL-DYY12C ,
CCL-DYY12.

Note:
You can also only select the transfering core of CCL-DYCZ40D if you have already bought CCL-DYCZ24D or CCL-DYCZ24DN because the external tanks and the lids of these two models are the same.
