Full Digital Color Doppler Ultrasound System With Convex and Linear Probe

Item Code: CCBQ3
Sold: 33
Write a review
Share this:
Have a question?
    Please select the information you wantX
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
+
-
Units
Add to Favorite Items
  • Description
Specifications
Application: Abdomen, OB/GYN, Small Parts, Vascular, Cardiology, Anaesthesia, Emergency, ICU, Breast, 4D Style: Trolley Types: Color Doppler


Configuration:
Main Unit---1
Convex Probe---1
Linear Probe---1

 2.1 Dimension and weight
  1.  Width: approx. 565mm
  2.  Height:  approx. 1455mm
  3.  Thickness:  approx.845mm
  1.  Weight: approx. 70kg
2.2 Monitor
  1. 15-inch high resolution color display screen
  2.  Resolution: 1024*768
  3. Rotate angle range 90°(L/R)
  4. Tilt angle range 0-90°(U/D)
2.3  Touch Screen
  1. 10.4-inch touch screen
  2.  Resolution: 1024*768
2.4 Probe ports and holders
  1.  4 activated Probe ports
  2.  4 removable Probe holders
  3.  4 probe wire hook
    2.5  Electrical power
  1. Voltage :  AC 100V ~ 240V
  2. Input Fuse:   φ5×20 mm,F3.15AL250V AC
  3. Output Fuse:  φ5×20 mm,F2AL250V  AC
  4. Frequency:  50/60Hz
  5. Power:  320VA
    2.6 Operation Environment
  1. Ambient temperature: 5℃~+40℃
  2. Relative humidity: 25%~85%
  3. Atmospheric pressure:  70kpa ~ 106kpa
2.7  Storage &Transport Environment
  1. Ambient temperature: -20℃~+55℃
  2. Relative humidity: 10%~95%
  3. Atmospheric pressure:  50kpa-106kpa

Shipping Information:

G.W: 100kg

Packing Size: 0.69m,0.8m,1.36m

Unit: Piece
