Description

Specifications

Features:
1. Five level zoom in zoom out and focus, strong stereoperception, distinct gradation, wide vision field.
2. Build-in ruler, can measure pathological changes tissue.
3. Integrated design double light road light source and fiber guider, the brightness can be adjusted.
4. Special green filter, convenient for doctor to examine the change of blood capillary.
5. Rocker arm stand, the wheel can be locked, can be adjusted in any angle.
6. High resolution 1/3’’ color CCD, real-time display the image which you see through the optic eyepiece.
7. Unique spectro-grating design and CCD image micromatic setting device, make image stereoscopic,
make the diseased tissue at different levels get the best observe effect

Technical Parameters:
China brand microscope: Observation angle:  45° tilted
Magnification of eyepiece: 16X
Focal length of objective:  F=230mm & F=280mm
Magnification changer 5-step:  0.4X, 0.6X, 1X, 1.6X, 2.5X
Optical Magnification: 4x-25x
Working distance:  250mm - 350mm
Linear field:  11mm-84mm
Fine focusing distance:  +-9mm
Beam Splitter:  50:50 Beam splitter
Illumination: Coaxial illumination with cold light source fiber-optic cable, brightness adjustable
Lamp:  21V150W halogen lamp or 250W xenon light
Filter:  Build-in green filter
Service manuals: Chinese/English version

Standard Configuration:
1) Durable trolley                                 1 set
2) Special medical design computer     1 set
3) CCD camera                                     1 set
4) Special video capture card               1 pc
5) Colposcope holder                           1 set
6) China brand optical microscope       1 set
7) Power line                             1 pc
8) User manual                          1 pc
9) Certificate                              1 pc
10) Packing list                          1 pc
11) HP color inkjet printer          1 pc
