- Description
Product Details
Product feature
1.Adopt imported gas spring, durable and wear well.
2.The table has three sections, patient can choose an appropriate position for the convenience of treatment.
3.Equipped with lifting and moving casters to make movement more convenient.
4.It can be used either in manual treatment or acupotomologic therapy for minimally invasive spine surgery or joint diseases, so it can also be called a special table for minimally invasive spine surgery.
5.Bed body adopts double motor and gas spring lifting adjustment mode, easy operation.
6.With leg adjustment screw, regardless of any ground, the multi-position treatment bed can be adjusted.
7.With patient breathing hole and shoulder hole.
8.With CE certificate.
Parameters
Model |
CCRF3 |
Power supply |
AC220V 50Hz. |
Rated input power |
190VA |
The maximum loads |
200kg |
Specifications (mm) |
1970 x 660 x 570 ~ 870. |
Lifting function |
Bed lifting stroke is continuously adjustable from 0 to 300mm. |
Head section function |
Relative to the horizontal adjustment angle: -20 ° ~ +30 ° continuously adjustable |
Lumbar thoracic function |
Relative to the horizontal adjustment angle: 0 ° ~ +25 ° continuously adjustable. |
Lower body segment function |
Relative to the horizontal adjustment angle: -25 ° ~ +40 ° continuously adjustable. |
Shipping Information:
G.W: 122.5kg
Packing Size: 2.16m,0.72m,0.83m
Unit: Piece
Special: No
